| TECHNICAL SPECIFICATION | UNIT | SB 690MINI | SB 690WCB MINI | SB 690WCB3 MINI |
| Bale Size | cm | 36 x 46 | 36 x 46 | 36 x 46 |
| Piston Bearing | per/min. | 73 | 73 | 73 |
| Piston Stroke | Stroke/min. | 104 | 104 | 104 |
| Pickup Width | cm | 150 | 180 | 180 |
| Bale Size | cm | 30 - 130 | 30 - 130 | 30 - 130 |
| Bale Weight (Straw) | KG | - | - | - |
| Bale Weight (Grass) | KG | 25 - 35 | 25 - 35 | 25 - 35 |
| Total Length (in Work Position) | cm | 650 | 650 | 650 |
| Total Length (In Road Position) | cm | 497 | 497 | 497 |
| Total Width | cm | 228 | 252 | 252 |
| Total Height | cm | 190 | 190 | 190 |
| Left Wheel Size |
|
10.0 / 75 - 15.3 | 10.0 / 75 - 15.3 | 10.0 / 75 - 15.3 |
| Chopper Size | cm | - | - | - |
| Right Wheel Size |
|
10.0 / 80 -12 | 10.0 / 80 -12 | 10.0 / 80 -12 |
| Machine Weight | KG | 1700 | 1800 | 1850 |
| Minimum Required Tractor Power | KW / BG | 48.5 / 65 | 48.5 / 65 | 48.5 / 65 |
| Pitchfork System |
|
3 | 3 | 3 |
| Collector Lift |
|
ѵ | ѵ | ѵ |
| Knotting System Fan |
|
ѵ | ѵ | ѵ |
| Bale Counter |
|
ѵ | ѵ | ѵ |
| Machine Lighting and Signaling |
|
ѵ | ѵ | ѵ |
| Knotting System | RASSPE | 2 Twines | 2 Twines | 3 Twines |
| Number of Bales per Day |
|
1650 qty/day | 1800 qty/day | 1800 qty/day |
